Diaphragm Valve

Valve Solutions For Corrosive Applications

PP/ISO.PP/PPH
/PVDF Socket Weld Ends

Inquire Now Download
Go Back
Lined Swing Check Valve

Valve Solutions For Corrosive Applications

PP/ISO.PP/PPH/PVDF
Socket Weld Ends

Inquire Now Download

Dimension Table

Size(OD) E d H F T
25mm 33 25 23 44 7
32 MM 41 32 26 50 10
50 MM 63 50 35 77 12
63 MM 76 63 37 90 14
90 MM 109 90 47 125 16
110 MM 131 110 55 150 18
160 MM 188 160 70 216 18
200 MM 228 200 90 275 22
